Blue Sea C-Series Flat Rocker Circuit Breaker Double Pole 50A AC

Blue Sea C-Series Flat Rocker Circuit Breaker Double Pole 50A AC

Vendor: Blue Sea
SKU: wt-BSS7561
Availability: Out Of Stock
$123.09
$178.07
$123.09
Subtotal: $123.09
Description
Description
x

Blue Sea Systems C-Series Flat Rocker Circuit Breaker - Double Pole 50A AC

Model: 7561-BSS
  • 5,000 Ampere interrupt capacity to meet ABYC requirements for 120/240 Volt 50 Ampere main protection
  • Double pole can be used as 120 Volt AC main circuit breaker to switch hot and neutral
  • Triple pole can be used as 240 Volt AC main circuit breaker to switch both lines (hots) and neutral
  • Circuit breakers will trip all poles if any one pole trips
  • "Trip Free" design cannot be held "ON" during fault current condition
Specifications
Amperage 50A AC
Actuator Style Flat Rocker
Poles 2
Maximum Voltage 120V AC / 240V AC
Circuit Breaker Type Magnetic Hydraulic - trip free
Terminal Stud 1/4-20 Tin-Plated Brass
Terminal Stud Torque 35 in-lb (3.95 Nm)
Interrupt Capacity 5000A @ 48V DC
Minimum Operating Temperature -40 deg C
Maximum Operating Temperature 85 deg C
Mounting Screw 6-32 Stainless Steel
Mounting Screw Torque 6 in-lb (0.68 Nm)
Switching Cycles 10000
Weight 0.64lb (0.29 kg)


WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Brand: Blue Sea

UPC: 632085075613

Model Number: 7561-BSS

Weight: 0.64
